BP; Hydraulic; 10 x 2-1/4in; R/H free backing
- Brake Backing Plate
- Hydraulic; 3500lb
- 10in x 2-1/4in
- L/H
- Free Backing
Have any questions? Feel Free to Get in Touch
Customer specification worksheet
Light-Duty Axle Order Form
Leaf spring suspension · 2,000–8,000 lb capacity
Hydraulice free backing brakes incorporates a “fall-away” shoe which diminishes shoe drag when backing up. This allows backing up without A: using manuel or electonic lock outs and B: backing up without applying the trailer brakes. These brakes requires periodic manual adjustment.
Marine-grade hydraulic drum brake assembly is great for boat trailers
Designed for use with surge-type trailer brake actuators
Sturdy, corrosion-resistant steel construction
Specifications:
Galvanized backing plate
Stainless steel spring hardware
Plated wheel cylinder
Riveted marine brake shoe
Left hand: Drivers side
Dimensions: 10″ diameter x 2-1/4″ wide
Individual brake rating: 1750lbs
Mounting flange bolt pattern: 4 on 4″
Wheel size: 13″ – 15″
Axle rating: up to 3500lbs
Note: This brake assembly is compatible with any surge brake actuator rated for drum brakes (1000PSI rated)
